HUMMER H1 1992-2006 fluids type and filling capacities
Recommended engine oil, transmission fluids, coolant type, filling capacities and service intervals for HUMMER H1 1992-2006.
| Agregate | Recomeded fluid | Capacity (L) | Intervals |
| 5,7L gasoline engine (L05) | 5W30 (Dexos1) | 4,8 | 5000 km (3000 miles) |
| 6,2L and 6,5L diesel engines | Above -18 degree C: 15W40 API CF-4 Below -18 degree C: 10W30 API CF-4 |
7,6 (dry fill - 9,5) | 5000 km (3000 miles) |
| 6,6L diesel engine (Duramax) | Above -18 degree C: 15W40 API CJ-4 or CK-4 Below -18 degree C: 5W40 API CJ-4 or CK-4 |
9,5 | 5000 km (3000 miles) |
| Cooling system | DEX-COOL Coolant | ~ 25,0 | 240000 km (150000 miles) or 5 years |
| 3-speed automatic transmission (3L80) | DEXRON II or III | 5,7 (service fill) 10,4 (overhaul fill) |
72000 km (45000 miles) |
| 4-speed automatic transmission (4L80E) | DEXRON III | 7,3 (service fill) 12,8 (overhaul fill) |
72000 km (45000 miles) |
| 5-speed automatic transmission (Allison 1000) | DEXRON VI or Alison ATF TES-295 | 7,0 (service fill) | 72000 km (45000 miles) |
| Transfer case | DEXRON II | 3,3 | 72000 km (45000 miles) |
| Front differential | 80W90 API GL-5 | 1,9 | |
| Rear differential | 80W90 API GL-5 | 1,9 | |
| Hub Gear | 80W90 API GL-5 | 0,5 * 4 | |
| Hydraulic Power Steering System | DEXRON II or III | 1,0 | |
| Hydraulic Brake System | DOT3 | 1,5 | 2 Years |
| Ball joints, Tie Rod Ends, Pitman Arm, Propeller Shafts | GAA Grease | 1000 miles | |
Information of this table may be incorect for your region or driving conditions. Refer to the owners/service manual for details.
