HYUNDAI i30 GD 2011-2015 fluids type and filling capacities

Recommended engine oil, transmission fluids, coolant type, filling capacities and service intervals for HYUNDAI i30 GD 2011-2015.
Aggregate | Recommeded fluid | Capacity (Liters) | Intervals |
1,4L and 1,6L petrol engines (G4FA / G4FC / G4FD) | 5W-20 or 5W-30 API SM or above; ACEA A5 or above
|
3,6 | 7500 km (4500 miles) or 6 months, whichever comes first |
1,6L petrol turbo engine (G4FJ) | Europe: 5W-30 API SM or above; ACEA A5 or above
Except Europe: 5W-40 API SM or above; ACEA A5 or above |
4,5 | 7500 km (4500 miles) or 6 months, whichever comes first |
1,8L and 2,0L petrol engines (G4NB and G4NC) | 5W-20 or 5W-30 API SM or above; ACEA A5 or above
|
4,0 | 7500 km (4500 miles) or 6 months, whichever comes first |
1,4L and 1,6L diesel engine (D4FC and D4FB) | With DPF: 5W-30 ACEA C2 or C3;
without DPF: 5W-30 ACEA B4 |
5,3 | 7500 km (4500 miles) or 6 months, whichever comes first |
Manual gearbox | 75W-85 API GL-4
|
2,0 | 120000 km (80000 miles) |
Automatic gearbox | HYUNDAI ATF SP-IV
|
7,3 | 90000 km (60000 miles) |
Dual clutch gearbox | HYUNDAI MTF&DCTF SAE 70W API GL-4
p/n: 04300-KX1B0 or 00232-19063 |
2,0 | 120000 km (80000 miles) |
Coolant (1,4L / 1,6L / 1,8L / 2,0 petrol engines) | Ethylene glycol base coolant for aluminium radiator
|
5,9 | At first, replace at 210000 km (120000 miles) or 10 years: after that, replace every 30000 km (20000 miles) or 24 months |
Coolant (1,6L turbo) | Ethylene glycol base coolant for aluminium radiator
|
6,5 | At first, replace at 210000 km (120000 miles) or 10 years: after that, replace every 30000 km (20000 miles) or 24 months |
Coolant (1,4 and 1,6L diesel) | Ethylene glycol base coolant for aluminium radiator
|
6,9 | At first, replace at 210000 km (120000 miles) or 10 years: after that, replace every 30000 km (20000 miles) or 24 months |
Brake and Clutch fluid | FMVSS116 DOT-3 or DOT-4
|
0,8 | 30000 km (20000 miles) or 24 months |
Information in this table may be incorrect for your region or driving conditions. Refer to the owners/service manual for details.
