TOYOTA Sienna XL30 2011-2020 fluids type and filling capacities

Recommended engine oil, transmission fluids, coolant type, filling capacities and service intervals for TOYOTA Sienna XL30 2011-2020.
Aggregate | Recommeded fluid | Capacity (Liters) | Intervals |
2,7L gasoline engine (1AR-FE) | 0W20 ILSAC GF-5 or above; with API certification mark
|
4,4 | 8000 km (5000 miles) or 6 months |
3,5L gasoline engine (2GR-FE) | 0W20 ILSAC GF-5 or above; with API certification mark
|
6,1 | 8000 km (5000 miles) or 6 months |
3,5L gasoline engine (2GR-FKS) | 0W20 ILSAC GF-5 or above; with API certification mark
|
5,5 | 8000 km (5000 miles) or 6 months |
Cooling system (1AR-FE) | Toyota Super Long Life Coolant
|
8,7 | 160000 km (100000 miles) or 120 months |
Cooling system (2GR-FE) | Toyota Super Long Life Coolant
|
10,4 - 11,1 | 160000 km (100000 miles) or 120 months |
Cooling system (2GR-FKS) | Toyota Super Long Life Coolant
|
11,5 - 11,8 | 160000 km (100000 miles) or 120 months |
6-speed automatic transmission (U660E) | Toyota ATF WS
|
6,5 - 6,7 | 96000 km (60000 miles) or 72 months |
8-speed automatic transmission (UA80F) | Toyota ATF WS
|
7,5 | 96000 km (60000 miles) or 72 months |
Transfer case (AWD models) | 75W-85 API GL-5 Toyota Genuine Differential Gear Oil LT or equivalent
|
0,8 | 24000 km (15000 miles) or 18 months |
Rear differential (AWD models) | 75W-85 API GL-5 Toyota Genuine Differential Gear Oil LT or equivalent
|
0,5 | 24000 km (15000 miles) or 18 months |
Brake hydraulic system | DOT3
|
Information in this table may be incorrect for your region or driving conditions. Refer to the owners/service manual for details.
