AUDI A4 / S4 / RS4 B9 2016- fluids type and filling capacities

A4 / S4 / RS4 B9 2016-
Recommended engine oil, transmission fluids, coolant type, filling capacities and service intervals for AUDI A4 / S4 / RS4 B9 2016-.
Agregate Recomeded fluid Capacity (L) Intervals
1,4L petrol engine (TFSI) VW50800 or VW50200 4,3 10000 km or 1 year
2,0L petrol engine (TFSI) VW50800 or VW50200 5,2 10000 km or 1 year
2,0L petrol engine (G-Tron and MHEV models) VW50800 5,2 10000 km or 1 year
2,9L petrol engine VW50400 7,6 10000 km or 1 year
3,0L petrol engine VW50800 or VW50200 7,3 10000 km or 1 year
2,0L diesel engine VW50700 4,7 10000 km or 1 year
3,0L diesel engine VW50700 or VW50900 6,1 10000 km or 1 year
Cooling system (up to 2018 MY) VAG G13 Antifrezee
p/n: GA13A8JM1
Cooling system (from 2019 MY) VAG G13 Antifrezee
p/n: GA13774M2
6-speed manual transmission (0DJ, Gearbox code - PZE, PZF, PZG, PZJ, RKD) p/n: G052549A2 2,5
6-speed manual transmission (0DJ, Gearbox code - PZH, RYH, RYJ, RYK, RYL, RYN) p/n: G052549A2 1,8
6-speed manual transmission (0CS) p/n: G052549A2 2,5
6-speed manual transmission (0CX) p/n: G052549A2 1,8
7-speed DTC transmission (DSG 0CK and 0CL and 0CJ) Automatic part - p/n: G055529A2
Mechanic part - p/n: G052549A2
Automatic part - 4,4
Mechanical part - 3,8
60000 km
8-speed automatic transmission (0D5) p/n: G060162A2 9,0 60000 km
Transfer case or AWD clutch (with 0CX and 0CJ and 0CL transmissions) p/n: G055515A2 0,4
Transfer case (with 0D5 transmission) p/n: G055145A2 0,8
Front differential (with 0D5 transmission) p/n: G052145S2 0,9
Rear differential (0DB and 0D2) p/n: G055190A2 0,7 - 0,9
Rear differential (0D3, QQS) Central part - p/n: G055190A2
Right and Left part - p/n: G055515A2
Central part - 1,0
Right and Left part - 0,9
Rear differential (0B0 and 0G2) p/n: G060190A2 1,0
Brake and Clutch DOT4 (VW 501.14)
p/n: B000750M3
1,0 2 years

Information of this table may be incorect for your region or driving conditions. Refer to the owners/service manual for details.
