CADILLAC ATS / ATS-V 2013-2019 fluids type and filling capacities

Recommended engine oil, transmission fluids, coolant type, filling capacities and service intervals for CADILLAC ATS / ATS-V 2013-2019.
Agregate | Recomeded fluid | Capacity (L) | Intervals |
2,0L petrol turbocharged engine (LTG) | 5W30 (dexron1) | RWD - 4,7 AWD - 5,7 |
5000 km (3000 miles) |
2,5L petrol engine (LCV) | 5W20 or 0W20 (dexron1) | 4,7 | 5000 km (3000 miles) |
3,6L petrol engines (LFX/LGX) | 5W30 (dexron1) | RWD - 5,7 AWD - 6,2 |
5000 km (3000 miles) |
3,6L petrol turbocharged engine (LF4) | 5W30 (dexron1) | 6,6 | 5000 km (3000 miles) |
Cooling system (2,0L and 2,5L) | DEX-COOL Coolant | 8,1 - 8,8 | 240000 km (150000 miles) or 5 years |
Cooling system (3,6L LFX/LGX) | DEX-COOL Coolant | 10,0 - 10,6 | 240000 km (150000 miles) or 5 years |
Cooling system (3,6L LF4, Engine) | DEX-COOL Coolant | Engine - 11,6 Intercooler - 3,1 |
240000 km (150000 miles) or 5 years |
6-speed manual transmission (Tremec TR3160, M3L) | DEXRON-VI | 2,7 | 72000 km (45000 miles) |
6-speed manual transmission (Tremec TR6060, MG9, ATS-V) | GM MTF p/n: 88861800 | 4,8 (overhaul fill) | 72000 km (45000 miles) |
6-speed automatic transmission (6L45 Hydra-Matic) | DEXRON-VI | 7,0 (service fill) 10,8 (overhaul fill) |
72000 km (45000 miles) |
8-speed automatic transmission (8L45/90 Hydra-Matic) | DEXRON-HP | 7,0 (service fill) 10,8 (overhaul fill) |
72000 km (45000 miles) |
Transfer case (AWD) | Transfer Case Fluid p/n: 88861950 | 0,8 | 72000 km (45000 miles) |
Front differential | 75W90 Synthetic Gear Oil p/n: 12378261 or 88863089 | 0,4 | 72000 km (45000 miles) |
Rear differential (195 mm, non-LSD) | 75W90 Synthetic Gear Oil p/n: 88863089 | 0,9 | 72000 km (45000 miles) |
Rear differential (218 mm, LSD) | 75W90 LSD Synthetic Gear Oil p/n: 88862624 | 1,0 | 72000 km (45000 miles) |
eLSD Clutch System Lubricant | DEXRON-VI | ~ 1,0 | 72000 km (45000 miles) |
Brake and Clutch | DOT3 or DOT4 | 2 years |
Information of this table may be incorect for your region or driving conditions. Refer to the owners/service manual for details.
