AUDI Q5 / SQ5 8R 2009-2017 fluids type and filling capacities

Recommended engine oil, transmission fluids, coolant type, filling capacities and service intervals for AUDI Q5 / SQ5 8R 2009-2017.
Agregate | Recomeded fluid | Capacity (L) | Intervals |
2,0L petrol engine | VW50200 or VW50400 | 4,6 | 10000 km or 1 year |
2,0L diesel engine | VW50700 | 5,0 | 10000 km or 1 year |
3,0L diesel engine | VW50700 | 6,9 | 10000 km or 1 year |
3,0L petrol engine | VW50200 or VW50400 | 6,8 | 10000 km or 1 year |
3,2L petrol engine | VW50200 or VW50400 | 6,2 | 10000 km or 1 year |
Cooling system | VAG G13 antifreeze p/n: G012A8GA3 p/n: GA13A8JM1 or GA13040M2 |
||
6-speed manual transmission (0B1) | p/n: G052532A2 | 4,0 | |
6-speed manual transmission (0B2) | p/n: G055532A2 | 4,5 | |
6- and 8-speed automatic transmissions (0B6 and 0BK and 0BW) | p/n: G060162A2 | 9,0 | 60000 km |
7-speed DSG transmission (0B5, DL501) | Automatic part - p/n: G052529A2 Mechanic part - p/n: G052513A2 |
Automatic part - 7,0 Mechanical part - 5,0 |
60000 km |
7-speed DSG transmission (0CK) | Automatic part - p/n: G055529A2 Mechanic part - p/n: G052549A2 |
Automatic part - 3,5 Mechanical part - 3,8 |
60000 km |
Transfer case (with 0BW and 0BK and 0B6 transmissions) | p/n: G055145A2 | 1,0 | |
Front differential (0B6 and 0BW transmissions) | p/n: G052145S2(A1) | 1,1 | |
Front differential (0BK transmission, except gearbox codes: PFH, QDE, RNB) | p/n: G052145S2(A1) | 1,1 | |
Front differential (0BK transmission, with gearbox codes: PFH, QDE, RNB) | p/n: G055145A2 | 1,1 | |
Rear differential (0BC and 0BD) | p/n: G052145S2(A1) | ||
Rear differential (0BF, SQ5) | Central part - p/n: G052145S2(A1) Right and Left part - p/n: G055515A2 |
Central part - 0,9 Right and Left part - 1,0 |
|
Brake and Clutch | DOT4 p/n: B000750M3 |
1,0 | 2 years |
Information of this table may be incorect for your region or driving conditions. Refer to the owners/service manual for details.
