VOLKSWAGEN CC/Passat CC 2009-2017 fluids type and filling capacities
Recommended engine oil, transmission fluids, coolant type, filling capacities and service intervals for VOLKSWAGEN CC/Passat CC 2009-2017.
Share
Pin it
Post| Agregate | Recomeded fluid | Capacity (L) | Intervals |
| 1,4L petrol engine (CKMA) | VW 502.00 | 3,6 | QG0/QG1/QG2/QG3 - 15000 km or 1 year; QI1 - 5000 km or 1 year; QI2 - 7500 km or 1 year; QI3 - 10000 km or 1 year; QI4 - 15000 km or 1 year; QI6 - 30000 km or 2 year; QI7 - 10000 miles or 1 year; |
| 1,4L petrol engine (CTHD, CZDA) | VW 502.00 with QG0-QG3 and QI1-QI4/QI7; VW 504.00 with QI6 Refer to the vehicle data sticker and user manual |
3,6 - 4,0 | QG0/QG1/QG2/QG3 - 15000 km or 1 year; QI1 - 5000 km or 1 year; QI2 - 7500 km or 1 year; QI3 - 10000 km or 1 year; QI4 - 15000 km or 1 year; QI6 - 30000 km or 2 year; QI7 - 10000 miles or 1 year; |
| 1,8L and 2,0L petrol engines | VW 502.00 with QG0-QG3 and QI1-QI4/QI7; VW 504.00 with QI6 Refer to the vehicle data sticker and user manual |
4,7 | QG0/QG1/QG2/QG3 - 15000 km or 1 year; QI1 - 5000 km or 1 year; QI2 - 7500 km or 1 year; QI3 - 10000 km or 1 year; QI4 - 15000 km or 1 year; QI6 - 30000 km or 2 year; QI7 - 10000 miles or 1 year; |
| 3,6L petrol engine (BLV, BWS) | VW 502.00 with QG0-QG3 and QI1-QI4/QI7; VW 504.00 with QI6 Refer to the vehicle data sticker and user manual |
5,5 | QG0/QG1/QG2/QG3 - 15000 km or 1 year; QI1 - 5000 km or 1 year; QI2 - 7500 km or 1 year; QI3 - 10000 km or 1 year; QI4 - 15000 km or 1 year; QI6 - 30000 km or 2 year; QI7 - 10000 miles or 1 year; |
| 3,6L petrol engine (CNNA) | VW 502.00 | 5,5 | QG0/QG1/QG2/QG3 - 15000 km or 1 year; QI1 - 5000 km or 1 year; QI2 - 7500 km or 1 year; QI3 - 10000 km or 1 year; QI4 - 15000 km or 1 year; QI6 - 30000 km or 2 year; QI7 - 10000 miles or 1 year; |
| 2,0L diesel engine (CBAA, CBAB, CBAC, CBBB) | VW 507.00 | 4,0 | QG0/QG1/QG2/QG3 - 15000 km or 1 year; QI1 - 5000 km or 1 year; QI2 - 7500 km or 1 year; QI3 - 10000 km or 1 year; QI4 - 15000 km or 1 year; QI6 - 30000 km or 2 year; QI7 - 10000 miles or 1 year; |
| 2,0L diesel engine (CFFA, CFFB, CFGB, CFGC, CUVC, CUWA) | VW 507.00 | 4,3 - 4,6 | QG0/QG1/QG2/QG3 - 15000 km or 1 year; QI1 - 5000 km or 1 year; QI2 - 7500 km or 1 year; QI3 - 10000 km or 1 year; QI4 - 15000 km or 1 year; QI6 - 30000 km or 2 year; QI7 - 10000 miles or 1 year; |
| Cooling system | VAG G13 Antifreeze p/n: G013A8JM1 or G013774M2 |
||
| 6-speed automatic transmission (09M and 09G) | VAG ATF p/n: G055025A2 |
3,0L (service fill) 7,0L (overhaul fill) |
60000 km |
| 6-speed manual transmission (02S, Gearbox code: JWX) | p/n: G052171A2 | 1,9 - 2,1 | 60000 km |
| 6-speed manual transmission (02S, Gearbox code: except JWX) | Up to 03.12.2013 - p/n: G052512A2 From 04.12.2013 - p/n: G052527A2 |
1,9 - 2,1 | 60000 km |
| 6-speed manual transmission (02Q) | Up to 28.10.2013 - p/n: G052171A2 From 29.10.2013 - p/n: G052527A2 |
2,3 | 60000 km |
| 6-speed DSG transmission (DQ250, 02E) | p/n: G052182A2 | 5,2L (service fill) 7,2L (overhaul fill) |
60000 km |
| 7-speed DSG transmission (DQ200, 0AM) | Gearbox oil - p/n: G052512A2 Mechartonik oil - p/n: G004000M2 |
Gearbox oil - 1,7 Mechartonik oil - 0,9 |
60000 km |
| Transfer case (4Motion) | p/n: G052145S2 | 0,9 | |
| Rear differential clutch hydraulic system (4Motion) | p/n: G055175A2 | 0,8 | |
| Rear differential (4Motion) | p/n: G052145S2 | 0,9 | |
| Brake | DOT4 | 2 years | |
Information in this table may be incorect for your region or driving conditions. Refer to the owners/service manual for details.
